DJI FC100 Technical Specifications
| Parameter Category | Specific Parameter | Parameter Value | Notes |
|---|---|---|---|
| Flight Platform | Empty weight | 55.2 kg (lifting load) 60.2 kg (suspension load) |
Excluding battery, dual battery compartment, accessories, lifting rope, and hook weight |
| Maximum takeoff weight | 149.9 kg | Measured at sea level, 25°C. DJI Delivery App intelligently recommends load based on current conditions | |
| Maximum wheelbase | 2330 mm (diagonal) | – | |
| Dimensions (arms extended, propellers unfolded) | 3220 mm × 3224 mm × 975 mm | – | |
| Dimensions (arms extended, propellers folded) | 1820 mm × 1840 mm × 975 mm | – | |
| Dimensions (arms folded, propellers folded) | 1105 mm × 1265 mm × 975 mm | – | |
| Folding method | Fold towards the fuselage | – | |
| Number of onboard batteries | Supports dual battery and single battery | Single battery mode for emergency use only | |
| Overall protection rating | IP55 | Not permanent, may decrease with wear. Avoid flying in heavy rain | |
| Flight Performance | Maximum flight distance | At max takeoff weight: 12 km (dual battery), 6 km (single battery) | Measured at 15 m/s in windless environment at sea level, 25°C |
| Maximum hover time | At max takeoff weight: 12 min (dual battery), 6 min (single battery) | Measured in windless environment at sea level, 25°C | |
| Maximum flight time | At max takeoff weight: 14 min (dual battery), 7 min (single battery) | Measured at 15 m/s in windless environment at sea level, 25°C | |
| Operating temperature range | -20°C to 40°C | Solar radiation estimated at 960W/m² | |
| Maximum flight altitude | 6000 meters | Maximum safe altitude with dual batteries, no load (takeoff at 4500m) | |
| Maximum wind resistance | 12 m/s | Maximum wind resistance during takeoff and landing | |
| Maximum ascent speed | 5 m/s | Measured in dual battery mode at sea level, 25°C, windless | |
| Maximum descent speed | 5 m/s | Measured in dual battery mode at sea level, 25°C, windless | |
| Navigation & Positioning | Hovering accuracy | With RTK: ±10 cm (horizontal), ±10 cm (vertical) Without RTK: ±60 cm (horizontal), ±30 cm (vertical) |
– |
| GNSS | Full system: GPS + Galileo + BeiDou + GLONASS BeiDou version: BeiDou |
– | |
| Maximum horizontal flight speed | 20 m/s | Measured in dual battery mode at sea level, 25°C, windless | |
| Power System | Motor stator dimensions | 155 × 16 mm | – |
| Motor KV value | 60 rpm/V | – | |
| Propeller material | Carbon fiber composite | – | |
| Propeller size | 62 inches | Dual-blade folding propeller | |
| Number of rotors | 8 pairs | – | |
| Safety Systems | Safety system types | Front millimeter wave radar Rear radar (single board) Downward radar (single board) Lidar Four-eye vision system FPV |
– |
| Milliwave radar EIRP | <20 dBm (NCC/MIC/KC/CE/FCC) | – | |
| Field of View (FOV) | Lidar: 272° vertical, 60° horizontal Front radar: 360° horizontal, ±45° vertical Downward radar: ±12.5° left/right, ±22.5° front/rear Rear radar: ±45° left/right, ±45° front/rear Four-eye vision: 360° horizontal, 180° vertical |
– | |
| Maximum detection range | 60 meters | Range varies by environment and target characteristics | |
| Operating power consumption | Lidar: 6.5 W Front radar: 18 W Downward radar: 5 W Rear radar: 5 W |
– | |
| Communication Systems | DJI O4 transmission maximum range | FCC: 20 km CE: 10 km SRRC: 12 km MIC: 10 km |
Measured in open, interference-free environment |
| Operating frequency | 2.400GHz to 2.4835GHz 5.725GHz to 5.850GHz |
Supported bands vary by country/region | |
| Transmit power (EIRP) | 2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.8 GHz: <33 dBm (FCC), <30 dBm (SRRC), <14 dBm (CE) |
– | |
| Live view quality | 1080p/30fps | – | |
| 4G enhanced transmission | Supported | – | |
| Parachute System | Model | E2MSF-100A | – |
| Impact speed | ≤ 6 m/s | Measured at max takeoff weight, 100m deployment altitude | |
| Parachute type | Square parachute | Material: Nylon | |
| Minimum safe deployment altitude | 100 meters | Guaranteed stable descent speed at this altitude and above | |
| Operating temperature | -20°C to 40°C | – | |
| Protection rating | IP55 | – | |
| Deployment methods | Manual deployment, automatic deployment | With buzzer and light alarm | |
| Payload Systems | DJI FlyCart 100 suspension system (Premium) | Model: A2EWH-100A Dimensions: 960 × 805 × 669 mm Cable length: 0-30 meters Max cable speed: 1.2 m/s |
Supports weight measurement, emergency release, anti-swing mode |
| Hook charging method | Wireless charging, Type-C charging | Wireless charging requires hook to be fully retracted | |
| Hook battery life | 10 hours | Measured at sea level, 25°C, windless environment | |
| DJI lifting system (dual battery) | Model: A2EDL-100A Dimensions: 960 × 805 × 669 mm Rope length: 10 meters |
Supports weight measurement, emergency release | |
| Lighting system | Direction: Front, downward Control: Automatic, manual Max power: 46W |
– | |
| FPV camera | FOV: ±86° horizontal, 108° vertical | – | |
| Battery Specifications | DJI DB2160 intelligent flight battery | Weight: 14.7 kg Capacity: 41Ah Nominal voltage: 52V |
– |
| Cycle life | 1500 cycles / 24 months | Warranty covers 1500 cycles or 24 months, whichever comes first | |
| DJI C12000 smart charger | Model: CSX901-12000 Input: 175-520V AC (3-phase), 200-264V AC (single-phase) Output: 62V, 194A Max power: 12000W (3-phase), 3000W (single-phase) |
– | |
| Charging time | 9 minutes | 30% to 95% charge at 15-40°C, sea level | |
| D14000iE all-in-one inverter charging station | Fuel type: 92# gasoline or higher Fuel tank capacity: 30L Weight: 87±0.5 kg |
Includes 2kg wheels and handle weight | |
| Remote Controller | Model | TKPL 2 | Compatible with DJI Delivery App |
| Display | 7″ touchscreen, 1920×1200 resolution, 1400 cd/m² brightness | – | |
| Battery life | 3.8 hours (built-in battery) 3.2 hours (external battery) |
– | |
| Charging time | 2 hours (built-in or built-in + external) | With recommended 65W+ USB-C charger | |
| Operating temperature | -20°C to 50°C | Charging temperature: 5°C to 40°C | |
| Features | 4G enhanced transmission, RTK high-precision positioning, master-slave control support | Second remote controller sold separately | |
| Optional Accessories | DJI 4G enhanced transmission kit | Model: IG831T Dimensions: 43.5 × 23 × 7 mm Weight: ~11g |
Supports TDD-LTE/FDD-LTE/WCDMA |
| D-RTK3 multi-function base station | Dimensions: Φ163 × 89 mm Weight: ~1.26 kg Protection rating: IP67 |
Relay mode: 4 hours battery life Base station mode: 7 hours battery life |
|
| CC15000 vehicle charger | Model: CCX901-15000 Input: DC 300-500V Output: 62V, 287A Max power: 15000W |
Charging time: 8 minutes (30% to 95%) | |
| DJI battery insulation box | Operating temperature: -20°C to 40°C Storage temperature: -40°C to 85°C |
– |
